What will the tag identify?
Separate reusable assets and fixed storage locations from disposable stock labels. Record the object type, expected service period and where staff need to see or scan the tag.
Warehouse & Inventory Asset Tags
Inventory tags connect racks, bins, carts and reusable assets to a warehouse record. Select the code type from the scan workflow, then confirm viewing distance, surface and installation position.
How to narrow the range
Connect the physical tag to the inventory record.
- 1Object
Separate reusable assets, locations and disposable stock.
- 2Scan
Choose barcode, QR code or visible serial by workflow.
- 3Installation
Test the actual rack, bin, cart or equipment surface.
Product options
5 mil WH-AL-R-13x32-0.1
Anodized Aluminum asset tag, 0.5 x 1.25 in
- Material
- Anodized Aluminum
- Size
- 0.5 x 1.25 in
- Code
- Serial number / Barcode
$0.79/pc reference at 100
View details 5 mil WH-AL-R-13x44-0.1
Anodized Aluminum asset tag, 0.5 x 1.75 in
- Material
- Anodized Aluminum
- Size
- 0.5 x 1.75 in
- Code
- Serial number / Barcode
$0.87/pc reference at 100
View details
5 mil WH-AL-S-25x25-0.1
Anodized Aluminum asset tag, 1 x 1 in
- Material
- Anodized Aluminum
- Size
- 1 x 1 in
- Code
- Serial number / QR code
$0.98/pc reference at 100
View details 5 mil WH-AL-R-19x38-0.1
Anodized Aluminum asset tag, 0.75 x 1.5 in
- Material
- Anodized Aluminum
- Size
- 0.75 x 1.5 in
- Code
- Serial number / QR code
$0.98/pc reference at 100
View details 5 mil WH-AL-R-19x51-0.1
Anodized Aluminum asset tag, 0.75 x 2 in
- Material
- Anodized Aluminum
- Size
- 0.75 x 2 in
- Code
- Serial number / QR code
$0.79/pc reference at 100
View details
5 mil LBC-AL5-AL-R-19x64-0.10
Anodized Aluminum asset tag, 0.75 x 2.5 in
- Material
- Anodized Aluminum
- Size
- 0.75 x 2.5 in
- Code
- Serial number / QR code
$0.92/pc reference at 100
View details 8 mil LBC-AL8-AL-R-19x64-0.20
Anodized Aluminum asset tag, 0.75 x 2.5 in
- Material
- Anodized Aluminum
- Size
- 0.75 x 2.5 in
- Code
- Serial number / QR code
$2.28/pc reference at 100
View details
2 mil LBC-PET-PET-R-19x64-0.05
Polyester asset tag, 0.75 x 2.5 in
- Material
- Polyester
- Size
- 0.75 x 2.5 in
- Code
- Serial number / QR code
$1.95/pc reference at 100
View details 5 mil WH-AL-R-25x51-0.1
Anodized Aluminum asset tag, 1 x 2 in
- Material
- Anodized Aluminum
- Size
- 1 x 2 in
- Code
- Serial number / QR code
$0.91/pc reference at 100
View details 5 mil WH-AL-S-38x38-0.1
Anodized Aluminum asset tag, 1.5 x 1.5 in
- Material
- Anodized Aluminum
- Size
- 1.5 x 1.5 in
- Code
- Serial number / QR code
$0.96/pc reference at 100
View details 5 mil WH-AL-R-32x51-0.1
Anodized Aluminum asset tag, 1.25 x 2 in
- Material
- Anodized Aluminum
- Size
- 1.25 x 2 in
- Code
- Serial number / QR code
$1.01/pc reference at 100
View details 5 mil LBC-AL5-AL-R-25x67-0.10
Anodized Aluminum asset tag, 1 x 2.625 in
- Material
- Anodized Aluminum
- Size
- 1 x 2.625 in
- Code
- Serial number / QR code
$1.08/pc reference at 100
View details 8 mil LBC-AL8-AL-R-25x67-0.20
Anodized Aluminum asset tag, 1 x 2.625 in
- Material
- Anodized Aluminum
- Size
- 1 x 2.625 in
- Code
- Serial number / QR code
$2.68/pc reference at 100
View details 2 mil LBC-PET-PET-R-25x67-0.05
Polyester asset tag, 1 x 2.625 in
- Material
- Polyester
- Size
- 1 x 2.625 in
- Code
- Serial number / QR code
$2.29/pc reference at 100
View details 5 mil WH-AL-R-25x76-0.1
Anodized Aluminum asset tag, 1 x 3 in
- Material
- Anodized Aluminum
- Size
- 1 x 3 in
- Code
- Serial number / QR code
$1.10/pc reference at 100
View details 5 mil WH-AL-R-32x70-0.1
Anodized Aluminum asset tag, 1.25 x 2.75 in
- Material
- Anodized Aluminum
- Size
- 1.25 x 2.75 in
- Code
- Serial number / QR code
$1.18/pc reference at 100
View details 5 mil WH-AL-S-50x50-0.1
Anodized Aluminum asset tag, 2 x 2 in
- Material
- Anodized Aluminum
- Size
- 2 x 2 in
- Code
- Serial number / QR code
$1.27/pc reference at 100
View details 5 mil WH-AL-R-38x76-0.1
Anodized Aluminum asset tag, 1.5 x 3 in
- Material
- Anodized Aluminum
- Size
- 1.5 x 3 in
- Code
- Serial number / QR code
$1.34/pc reference at 100
View details 5 mil WH-AL-R-25x134-0.1
Anodized Aluminum asset tag, 0.98 x 5.28 in
- Material
- Anodized Aluminum
- Size
- 0.98 x 5.28 in
- Code
- Serial number / QR code
$1.43/pc reference at 100
View details 5 mil WH-AL-R-20x200-0.1
Anodized Aluminum asset tag, 0.8 x 7.875 in
- Material
- Anodized Aluminum
- Size
- 0.8 x 7.875 in
- Code
- Serial number / QR code
$1.57/pc reference at 100
View details 5 mil WH-AL-R-50x100-0.1
Anodized Aluminum asset tag, 2 x 4 in
- Material
- Anodized Aluminum
- Size
- 2 x 4 in
- Code
- Serial number / QR code
$1.75/pc reference at 100
View details 5 mil WH-AL-R-37x144-0.1
Anodized Aluminum asset tag, 1.46 x 5.67 in
- Material
- Anodized Aluminum
- Size
- 1.46 x 5.67 in
- Code
- Serial number / QR code
$1.75/pc reference at 100
View details 5 mil WH-AL-R-50x210-0.1
Anodized Aluminum asset tag, 2 x 8.25 in
- Material
- Anodized Aluminum
- Size
- 2 x 8.25 in
- Code
- Serial number / QR code
$1.75/pc reference at 100
View details 5 mil WH-AL-R-76x252-0.1
Anodized Aluminum asset tag, 3 x 9.9 in
- Material
- Anodized Aluminum
- Size
- 3 x 9.9 in
- Code
- Serial number / QR code
$1.75/pc reference at 100
View details 5 mil WH-AL-R-100x500-0.1
Anodized Aluminum asset tag, 4 x 19.7 in
- Material
- Anodized Aluminum
- Size
- 4 x 19.7 in
- Code
- Serial number / QR code
$3.60/pc reference at 100
View details Bulk ordering details
Custom Warehouse & Inventory Asset Tags: MOQ, reference pricing and production
Use these figures to check whether the listed range fits your requirement before requesting a quote. Final specifications and pricing are confirmed in writing.
- Minimum order
- 100pieces per specification
- Reference unit price
- $0.34–$3.35per piece at 1000 pieces
- Production after proof approval
- 4–8 business daysproduction time, not shipping time
Listed quantities: 100 / 300 / 500 / 1000 pieces.
$0.79–$3.60 per piece at the 100-piece minimum.
Production starts after you approve the proof.
- Materials, sizes and thicknesses
- Anodized Aluminum and Polyester in 2 mil, 5 mil and 8 mil. Rectangle and square, from 0.5 x 1.25 in to 4 x 19.7 in.
- Marking and variable data
- Custom text, logo, barcode, QR code, serial numbers and Excel/CSV variable data. Coded batches are scan-tested before shipment.
- Mounting and proof confirmation
- Adhesive, mounting holes and removable adhesive. Hole count, diameter and position are confirmed on the proof when required.
Reference prices are based on the listed specifications. Material, size, finish, mounting, marking and quantity may change the unit price by about US$0.30–US$0.60. Your written quote confirms the final price, tooling if required, production time and freight.
Warehouse application guide
Plan the tag around the asset, scan and inventory record.
Warehouse tags work only when the physical label and the inventory record use the same identifier. Define the asset, scanning method, surface and data file before choosing a size.
Should the code be a barcode, QR code or serial number?
Use the code already supported by the warehouse workflow. A barcode suits a defined scanner process, a QR code can open a web record, and a printed serial number gives staff a readable fallback.
Which material fits the location?
Polyester is a low-profile starting point for clean indoor surfaces. Anodized aluminum gives a metal face and includes adhesive or mechanical mounting choices in this Category. Confirm cleaning, impact and exposure on the quote.
How large should the tag be?
Base the size on code density, scanner distance, human-readable text and the available flat area. Leave space around the code and keep it clear of edges, seams and moving parts.
How will it attach?
Adhesive needs a clean contact area. Mounting holes, screws or rivets need an approved location and hole pattern. Test powder coat, texture, oil exposure and low-energy plastics before a full run.
How should variable data be supplied?
Use one spreadsheet row per tag. Keep asset ID, barcode value, QR destination and visible text in separate columns, preserve leading zeros and identify any number ranges that must not be used.
When is a sample test needed?
Test when the surface is curved, textured, coated, oily, repeatedly cleaned or exposed to condensation. Use the actual warehouse surface and cleaning method, not a substitute panel.
What belongs in the RFQ?
Send the asset or location type, tag size, quantity, code format, data file, surface photo, mounting preference and any cleaning or exposure conditions.
Application starting points
Use these as RFQ inputs. The approved Product and quote control the final specification.
| Condition | Starting point | Confirm before production |
|---|---|---|
| Clean indoor asset or location surface | Polyester or thin anodized aluminum with adhesive | Surface finish, contact area and cleaning method |
| Metal rack, cart or equipment with approved drilling | Anodized aluminum with mounting holes | Hole centers, fastener and clearance behind the surface |
| Scanner-led inventory workflow | Barcode plus human-readable asset ID | Symbology, scanner distance and data length |
| Phone access to a web record | QR code plus short visible serial number | Destination URL, access permissions and code size |
Current Product starting points
Every link below is a current member of this Category.
Thin metal for flat warehouse assets Anodized Aluminum
A 5 mil aluminum option gives a low-profile metal starting point.
0.5 x 1.25 in · 5 mil · Adhesive / Mounting holes · WH-AL-R-13x32-0.1 Open specification Thicker aluminum starting point Anodized AluminumUse the current 8 mil range when the quote calls for more body than the 5 mil option.
0.75 x 2.5 in · 8 mil · Adhesive / Mounting holes · LBC-AL8-AL-R-19x64-0.20 Open specification Indoor film label PolyesterPolyester is the current thin-film choice in this Warehouse and Inventory Category.
0.75 x 2.5 in · 2 mil · Adhesive / Removable adhesive · LBC-PET-PET-R-19x64-0.05 Open specificationFactory-direct — etched, marked & tested by us.
Every tag in this category is produced on our own lines in Shenzhen and scan-tested before it ships. See how we make them →
Choose the right spec for your environment.
| Material | Thickness | Finish / process | Mounting | Best environment | Sizes | Code support |
|---|---|---|---|---|---|---|
| Anodized Aluminum | 5 mil anodized aluminum | sub-surface printed | Adhesive / Holes | Outdoor, equipment, general durable | 1 x 1 in to 4 x 19.7 in (21 sizes) | Text, barcode, QR, serial |
| Anodized Aluminum | 8 mil anodized aluminum | sub-surface printed | Adhesive / Holes | Outdoor, equipment, general durable | 0.75 x 2.5 in to 1 x 2.625 in (2 sizes) | Text, barcode, QR, serial |
| Polyester | 2 mil durable film | thermal / digital printed | Adhesive | Indoor IT, office, inventory | 0.75 x 2.5 in to 1 x 2.625 in (2 sizes) | Text, barcode, QR, serial |
Explore adjacent ranges
Warehouse & Inventory Asset Tags — common questions
Pick metal or aluminum for rugged, long-life marking and durable film for lightweight, cost-effective indoor labels. Each product lists its material and specs.
Yes. Every tag supports custom text, logos, 1D/2D barcodes, QR codes, sequential serial numbers and Excel/CSV variable data.
Standard tiers are 100 / 300 / 500 / 1000 pieces with factory-direct pricing. Larger volumes or non-standard specs are available through Request a Custom Quote.
Not seeing your exact spec?
Send the size, material, quantity and marking data. We usually reply within one business day. The digital proof is free.
